Refusol 為德國生產之高品質逆變流器，在歐洲以性價比著稱。在太陽能系統中以穩定、高效能為名。 Photon雜誌近年評測中，為前十名的領導品牌。
| Technical Data | Advanced -energy / Refusol | Advanced -energy / Refusol | Advanced -energy / Refusol |
| Model | 013k | 017k | 020k |
| DC Max.PV power | 13.6kW | 18.1kW | 21.2kW |
| MPPT range | 420 - 850V | 445 - 850V | 480 - 850V |
| Max. DC voltage | 1000V | 1000V | 1000V |
| Max. DC current | 30A | 38.5A | 41A |
| MPP tracking | 1 | 1 | 1 |
| No. of DC connections | 4 x MC4 | 6 x MC4 | 6 x MC4 |
| DC-disconnection switch | Yes | Yes | Yes |
| Internal overvoltage | Type3 | Type3 | Type3 |
| Rated AC power | 12.4 kVA | 16.5 kVA | 19.2kVA |
| Max. AC active power | 12.4 kW | 12.4 kW | 12.4 kW |
| AC grid connection | 3 AC 400V + N, 50 - 60 Hz | 3 AC 400V + N, 50 - 60 Hz | 3 AC 400V + N, 50 - 60 Hz |
| Reted power factor | 1 | 1 | 1 |
| Adjustable displacement factor | 0.9i...1...0.9c | 0.9i...1...0.9c | 0.9i...1...0.9c |
| Max. AC current | 18A | 29A | 29A |
| Distorion factor THD | <1.8% | <1.8% | <1.8% |
| Max. efficiency | 98.00% | 98.20% | 98.20% |
| Infeed starting at | 20W | 20W | 20W |
| Internal consumption in night operation | <0.5W | <0.5W | <0.5W |
| Internal overvoltage protection | Type3 | Type3 | Type3 |
| Cooling | Natural convection | Natural convection | Natural convection |
| Ambient temperature | -25 ... +55 ℃ | -25 ... +55 ℃ | -25 ... +55 ℃ |
| -13 …+131℉ | -13 …+131℉ | -13 …+131℉ | |
| Elevation | Up to 2000 m above sea level | Up to 2000 m above sea level | Up to 2000 m above sea level |
| Noise | <45 dBa | <45 dBa | <45 dBa |
| Emitted interference | EN61000-6-4:2007 | EN61000-6-4:2007 | EN61000-6-4:2007 |
| Interence immunity | EN61000-6-2:2005 | EN61000-6-2:2005 | EN61000-6-2:2005 |
| Environmental classif | 4K4H acc. to DIN IEC 721-3-4 | 4K4H acc. to DIN IEC 721-3-4 | 4K4H acc. to DIN IEC 721-3-4 |
| Type of protection | IP65 as per EN60529 | IP65 as per EN60529 | IP65 as per EN60529 |
| Dimensions (W/H/D) | 535mm*601mm*277mm | 535mm*601mm*277mm | 535mm*601mm*277mm |
| Weight | 35.5 kg | 41.5 kg | 41.5kg |
